2 hours metal Fire Door
with 30 min insulation
Fire Door Specification
Door Type : Fire rated hinged doors (Metallic) – FD 120 with 30 minutes Insulation
Shutter Thickness : 48mm
Fire Rating : 120 Minutes
Frame Size :
100 x 57mm GI Single Rebate
150 x 57mm GI Double Rebate
Criteria : Stability, Integrity & with Insulation
Standard & certification :
IS 3614 : 2021, BS 476 Part 20-22
construction details
- Frame and Shutter made of Pressed Galvanized Steel conforming to IS 277
- Steel Door Frame Profile constructed using butt/mitered joints
- Door Frame fitted with grooved Intumescent seal and Smoke seal around perimeter
- Frame Sheet Thickness – 1.2mm/1.6mm Galvanized Steel
- Shutter Sheet Thickness – 1.2mm Galvanized Steel
- Vision Panel – 2hrs fire rated clear glass
- Shutter Infill – Mineral Wool
- Finish – Powder coated finish in desired shade
recommended hardware
- Fire Rated SS Ball Bearing Hinges (100 x 75 x 3mm)
- Fire Rated Door Closer
- Fire Rated D Shaped Pull Handle
- Fire Rated Concealed Flush Bolt
finishes
- Powder Coating in desired RAL Shade Code
- Polyurethane Coating in desired RAL Shade Code
- Liquid Paint Finish
- Wooden Grain Finishes
optional hardware
- Mortise Dead Lock set with Cylinder –
Complete with D Shape Pull handle for Push / Pull Operations - Mortise Sash Lock with Cylinder –
Complete with Lever handle for Push / Pull Operations - Fire Rated Panic Bar for Push Side Operation & Fire Rated Panic Trim – Pull Side Operation
