2 Hrs Wooden Fire Door Specification

2 hrs Wooden Fire Door

Fire Door Specification

Door Type : Fire Rated Hinged Doors (Wooden Composite) – FD120
Shutter Thickness : 55mm
Fire Rating : 120 Minutes
Frame Size : 140mm x 70mm
Criteria : Stability, Integrity & with Insulation
Testing Standards :
IS 3614 – 2021, BS 476 Part 20-22

construction details

  • Wooden Door Frame made from Hardwood Mirandi / Teak Wood as per requirement.
  • Door Shutter – Internal Frame made of Hardwood with facing of 3mm thick commercial ply or Teak Veneer on both faces
  • Shutter Insulation – Sandwich type Fire rated mineral wool treated with fire retardant sealant & Calcium silicate board.
  • Vision Panel – 2Hrs fire rated clear glass
  • Intumescent fire / smoke seal 10x4mm at all three sides of door frame and shutters except bottom.
Supreme Metwood Wooden Fire Door Drawing

recommended hardware

  1. Fire Rated SS Ball Bearing Hinges (100 x 75 x 3mm)
  2. Fire Rated Door Closer
  3. Fire Rated D Shaped Pull Handle
  4. Fire Rated Concealed Flush Bolt

finishes

  1. Teak Veneer Finish
  2. Laminate Finish
  3. Liquid Paint Finish

optional hardware

  1. Fire Rated Mortise Dead Lock set with Cylinder –
    Complete with Fire Rated D Shape Pull handle for Push / Pull Operations
  2. Fire Rated Mortise Sash Lock with Cylinder –
    Complete with Fire Rated Lever handle for Push / Pull Operations
  3. Fire Rated Panic Bar for Push Side Operation & Fire Rated Panic Trim – Pull Side Operation
