60 mins Wooden Fire Door
Fire door Specification
Door Type : Fire Rated Hinged Doors (Wooden Composite) – FD60
Shutter Thickness : 45mm
Fire Rating : 60 Minutes
Frame Size : 115mm x 70mm
Criteria : Stability, Integrity & Insulation
Testing Standards :
IS 3614 – 2021, BS 476 Part 20-22
construction details
- Wooden Door Frame made from Hardwood Mirandi / Teak Wood as per requirement
- Door Shutter – Internal Frame made of Hardwood with facing of 3mm thick commercial ply or Teak Veneer on both faces
- Shutter Insulation – Sandwich type Fire rated mineral wool treated with fire retardant sealant & Calcium silicate board.
- Intumescent fire / smoke seal 10x4mm at all three sides of door frame and shutters except bottom.

recommended hardware
- Fire Rated SS Ball Bearing Hinges (100 x 75 x 3mm)
- Fire Rated Door Closer
- Fire Rated D Shaped Pull Handle
- Fire Rated Concealed Flush Bolt
finishes
- Teak Veneer Finish
- Laminate Finish
- Liquid Paint Finish
optional hardware
- Fire Rated Mortise Dead Lock set with Cylinder –
Complete with Fire Rated D Shape Pull handle for Push / Pull Operations - Fire Rated Mortise Sash Lock with Cylinder –
Complete with Fire Rated Lever handle for Push / Pull Operations - Fire Rated Panic Bar for Push Side Operation & Fire Rated Panic Trim – Pull Side Operation
